ASPEN–Evolution 1000MFD Max–Multi Function Display-FINANCE AVAILABLE

Hover over image to zoom

  • Image 1
  • FLEXIGROUP AVAILABLE ON THIS PRODUCT
GARMIN
CALL "0800 722 362" FOR PRICING

or make 4 interest-free payments of fortnightly with Afterpay More info

SKU:
1000MFD
Condition:
New
Weight:
5.00 KGS

 Product Description

FLEXIGROUP AVAILABLE ON THIS PRODUCT
TERMS AND CONDITIONS APPLY
afterpay is not available on this Product


Adding the Evolution 1000 MFD to your Aspen PFD doubles your display area and provides a flexible display environment.


Item Description

Built on the same platform as the Evolution 1000 Pro MAX PFD, the 1000 MFD MAX provides full PFD redundancy, duplicating all critical sensors and systems, the 1000 MFD MAX can instantly become a fully-functional backup PFD.

  • New vibrant colors with the latest aviation glass
  • Higher reliability and faster refresh rates with the latest generation processors
  • Chart and countdown timers
  • Height above ground level (AGL) on navigation and terrain maps
  • METAR flags on navigation map

Product highlights:

Built on the same platform as the Evolution 1000 Pro MAX PFD, the 1000 MFD MAX provides full PFD redundancy, duplicating all critical sensors and systems, the 1000 MFD MAX can instantly become a fully-functional backup PFD.

  • New vibrant colors with the latest aviation glass
  • Higher reliability and faster refresh rates with the latest generation processors
  • Chart and countdown timers
  • Height above ground level (AGL) on navigation and terrain maps
  • METAR flags on navigation map

1000 MFD MAX Features

New vibrant colors with the latest aviation glass

Higher reliability and faster refresh rate rates

Chart and countdown timers

Height above ground level (AGL) on navigation and terrain maps

METAR flags on navigation map







Sectional-style moving maps with hazard awareness overlays

Customizable screen layouts

Charts and geo-referenced airport diagrams*

Built-in backup battery

Built-in terrain awareness

Traffic overlay on map via interface**



Weather

WX500 Stormscope interface

Datalink weather

Specifications

  • Duplicate sensor set providing full PFD redundancy
  • Eliminates requirement for backup instruments (when installed with Evolution 1000 Pro MAX primary flight display)
  • Sectional-style moving maps with hazard awareness overlays
  • Charts and geo-referenced airport diagrams
  • Customizable screen layouts
  • Built-in backup battery and emergency GPS*

Evolution Hazard Awareness

  • Altitude intercept arc on navigation map and terrain screen
  • Built-in terrain awareness
  • Traffic overlay on map via interface**

Weather

  • WX500 Stormscope interface
  • Datalink weather***
  • Hi-res NEXRAD radar
  • Radar coverage map
  • Precipitation type (at surface)
  • Echo tops
  • Cloud tops
  • Winds aloft (by altitude)
  • Satellite mosaic (by altitude)
  • AIRMETS
  • SIGMETS
  • TFRs
  • Storm weather tracks
  • Lightning
  • METARS
  • TAFS
* Emergency GPS available with optional upgrade
** Requires ARINC 735A compatible traffic system
*** Requires Aspen EWR50 Weather Receiver or equivalent

General Specifications:

Overall Dimensions   3.50” W x 7.00”H x 4.15”D
Weight   2.9 lbs. with mounting bracket
Display Type   6.0” Diagonal TFT Active Matrix LCD
Display Resolution   400x760
Display Backlight   High Intensity White LED
Display Colors   16M

Operational Specifications:

Operating Temp   -20°C to +55°C
Storage Temp   -55°C to +85°C
Max Operating Altitude (unpress.)   35,000 ft.
Cooling   Integral Fan
Max Humidity   95% at 50°C
Input Voltage   +8 to +32 Volts DC
Max Current   2.4 Amps @ 28 Vdc  /  4.8 Amps @ 14 Vdc

I/O Specifications:

ARINC 429 Inputs   5 Low Speed
ARINC 429 Outputs   1 Low Speed
RS-232 Inputs   5
RS-232 Outputs   3
Pitot / Static   Quick Connect

Certification Specifications:

FAA and EASA Technical Standard Orders
TSO/ETSO: C2D, C3D, C4C, C6D, C8D, C10B, C106, C113

Software
RTCA DO-178B Level C

Environmental
RTCA DO-160E

Categories
See Environmental Qualification Sheet
